Class relations: Association

Author
Julian Nonino
Platform Engineer - DevOps
Table of Contents
Object-Oriented Programming - This article is part of a series.
Part 4: This Article

Key characteristics of association:

  • It represents a loose coupling between classes.
  • The associated classes can exist independently of each other.
  • The lifetime of one class is not tied to the lifetime of the other.
  • It can be unidirectional or bidirectional.

There are two main types of association:

  1. Unidirectional Association
  2. Bidirectional Association

Let’s explore each of these in more detail.

Unidirectional association
#

In a unidirectional association, one class knows about and can interact with another class, but not vice versa. This is a one-way relationship.

Here’s an example in Python:

class Customer:
    def __init__(self, name):
        self.name = name

class Order:
    def __init__(self, order_number, customer):
        self.order_number = order_number
        self.customer = customer  # This creates an association

    def display_info(self):
        return f"Order {self.order_number} placed by {self.customer.name}"

# Creating instances
customer = Customer("John Doe")
order = Order("12345", customer)

print(order.display_info())  # Output: Order 12345 placed by John Doe

In this example, the Order class has a unidirectional association with the Customer class. An Order knows about its associated Customer, but a Customer doesn’t know about its Orders.

Here’s a UML diagram representing this relationship:

classDiagram
    class Customer {
        +name: string
    }
    class Order {
        +order_number: string
        +customer: Customer
        +display_info()
    }
    Order --> Customer : places
end

The arrow in the diagram points from Order to Customer, indicating that Order knows about Customer, but not the other way around.

Bidirectional association
#

In a bidirectional association, both classes are aware of each other and can interact with each other. This is a two-way relationship.

Here’s an example in Python:

class Student:
    def __init__(self, name):
        self.name = name
        self.courses = []

    def enrol(self, course):
        self.courses.append(course)
        course.add_student(self)

    def display_courses(self):
        return f"{self.name} is enrolled in: {', '.join(course.name for course in self.courses)}"

class Course:
    def __init__(self, name):
        self.name = name
        self.students = []

    def add_student(self, student):
        self.students.append(student)

    def display_students(self):
        return f"{self.name} has students: {', '.join(student.name for student in self.students)}"

# Creating instances
student1 = Student("Alice")
student2 = Student("Bob")
math_course = Course("Mathematics")
physics_course = Course("Physics")

# enrolling students in courses
student1.enrol(math_course)
student1.enrol(physics_course)
student2.enrol(math_course)

print(student1.display_courses())
print(math_course.display_students())

In this example, there’s a bidirectional association between Student and Course. A Student knows about their Courses, and a Course knows about its Students.

Here’s a UML diagram representing this relationship:

classDiagram
    class Student {
        +name: string
        +courses: list
        +enrol(course)
        +display_courses()
    }
    class Course {
        +name: string
        +students: list
        +add_student(student)
        +display_students()
    }
    Student "0..*" <--> "0..*" Course : enrols in >
end

The double-headed arrow in the diagram indicates that both Student and Course are aware of each other. The “0..*” notation indicates that a Student can be enrolled in zero or more Courses, and a Course can have zero or more Students.

Association is a flexible relationship that can represent many real-world connections between objects. It’s important to choose between unidirectional and bidirectional associations carefully, as bidirectional associations can introduce more complexity and potential for errors if not managed properly.


References
#

  1. Gamma, E., Helm, R., Johnson, R., & Vlissides, J. (1994). Design Patterns: Elements of Reusable Object-Oriented Software. Addison-Wesley.
  2. Martin, R. C. (2017). Clean Architecture: A Craftsman’s Guide to Software Structure and Design. Prentice Hall.
  3. Fowler, M. (2002). Patterns of Enterprise Application Architecture. Addison-Wesley.
  4. Bloch, J. (2018). Effective Java (3rd ed.). Addison-Wesley.
  5. Phillips, D. (2018). Python 3 Object-Oriented Programming (3rd ed.). Packt Publishing.
  6. Lott, S. F. (2020). Object-Oriented Python: Master OOP by Building Games and GUIs. No Starch Press.
  7. Booch, G., Rumbaugh, J., & Jacobson, I. (2005). The Unified Modeling Language User Guide (2nd ed.). Addison-Wesley.

Cheers for making it this far! I hope this journey through the programming universe has been as fascinating for you as it was for me to write down.

We’re keen to hear your thoughts, so don’t be shy – drop your comments, suggestions, and those bright ideas you’re bound to have.

Also, to delve deeper than these lines, take a stroll through the practical examples we’ve cooked up for you. You’ll find all the code and projects in our GitHub repository learn-software-engineering/examples.

Thanks for being part of this learning community. Keep coding and exploring new territories in this captivating world of software!
