Class relations: Inheritance

Key characteristics of inheritance:

• It promotes code reuse and establishes a hierarchy between classes.
• The subclass inherits all public and protected members from the superclass.
• The subclass can add its own members and override inherited members.
• It supports the concept of polymorphism.

Let’s look at an example to illustrate inheritance:

class Animal:
    def __init__(self, name):
        self.name = name

    def speak(self):
        pass

class Dog(Animal):
    def speak(self):
        return f"{self.name} says Woof!"

class Cat(Animal):
    def speak(self):
        return f"{self.name} says Meow!"

# Creating instances
dog = Dog("Buddy")
cat = Cat("Whiskers")

print(dog.speak())  # Output: Buddy says Woof!
print(cat.speak())  # Output: Whiskers says Meow!

# Demonstrating polymorphism
def animal_sound(animal):
    print(animal.speak())

animal_sound(dog)  # Output: Buddy says Woof!
animal_sound(cat)  # Output: Whiskers says Meow!

In this example, we have a base class Animal and two derived classes Dog and Cat. Both Dog and Cat inherit from Animal and override the speak method.

Here’s a UML diagram representing this inheritance relationship:

classDiagram
    class Animal {
        +name: string
        +speak()
    }
    class Dog {
        +speak()
    }
    class Cat {
        +speak()
    }
    Animal <|-- Dog
    Animal <|-- Cat
end

In this diagram, the arrows pointing from Dog and Cat to Animal indicate inheritance. This shows that Dog and Cat are subclasses of Animal.

Inheritance is a powerful feature of OOP, but it should be used judiciously. Overuse of inheritance can lead to complex class hierarchies that are difficult to understand and maintain. The principle of “composition over inheritance” suggests that it’s often better to use composition (has-a relationship) rather than inheritance (is-a relationship) when designing class relationships.

References

#

1. Gamma, E., Helm, R., Johnson, R., & Vlissides, J. (1994). Design Patterns: Elements of Reusable Object-Oriented Software. Addison-Wesley.
2. Martin, R. C. (2017). Clean Architecture: A Craftsman’s Guide to Software Structure and Design. Prentice Hall.
3. Fowler, M. (2002). Patterns of Enterprise Application Architecture. Addison-Wesley.
4. Bloch, J. (2018). Effective Java (3rd ed.). Addison-Wesley.
5. Phillips, D. (2018). Python 3 Object-Oriented Programming (3rd ed.). Packt Publishing.
6. Lott, S. F. (2020). Object-Oriented Python: Master OOP by Building Games and GUIs. No Starch Press.
7. Booch, G., Rumbaugh, J., & Jacobson, I. (2005). The Unified Modeling Language User Guide (2nd ed.). Addison-Wesley.
